Permanent Magnet Brush Dc Motor 63ZYT Series JK63ZYT02A-24V 3100Rpm 0.31mN.m 100W L=110mm Brushed Motor

Jkongmotor 24V 63ZYT Series brushed dc motor (JK63ZYT02A 24V) with 3100Rpm speed and size 63x63x110 mm. It has 2 wires,0.31mN.m and 100W. For more different dc brush motors requirements (such as gearbox, brake, encoder, or other parts), please contact us!!!

Electrical Specifications：

• Type: 24V 3100Rpm Brushed Dc Motor

• Model Name: JK63ZYT02A-24V

• Rated Voltage: 24V (Option for 12v up to 60vdc)

• Rated Speed: 3100Rpm

• No Load Speed: 3600Rpm


• Rated Torque: 0.31mN.m

• Rated Power: 100W

• Protection Level: IP50

• Optional Parts: Customized Voltage, Winding, Shaft, Mounting, and Lead Configurations, EMI/RFI Suppression Circuit, Thermal Protection, High Temperature Class H Insulation...





Physical Specifications:

• Frame Size: 63 x 63mm

• Body Length: 110mm

• Shaft Diameter: 5mm

• Number of Leads: 2

• Leads Length: 300mm

• Weight: 1.20g
