Permanent Magnet Brush Dc Motor 76ZYT Series JK76ZYT05A-24V 3200Rpm 0.90N.m 301W L=160mm Brushed Motor

Jkongmotor 24V 76ZYT Series brushed dc motor (JK76ZYT05A 24V) with 3200Rpm speed and size 63x63x160 mm. It has 2 wires,0.90N.m and 301W. For more different dc brush motors requirements (such as gearbox, brake, encoder, or other parts), please contact us!!!

Electrical Specifications：

• Type: 24V 3200Rpm Brushed Dc Motor

• Model Name: JK76ZYT05A-24V

• Rated Voltage: 24V (Option for 12v up to 220vdc)

• Rated Speed: 3200Rpm

• No Load Speed: 3800Rpm


• Rated Torque: 0.90N.m

• Rated Power: 301W

• Protection Level: IP50

• Optional Parts: Customized Voltage, Winding, Shaft, Mounting, and Lead Configurations, EMI/RFI Suppression Circuit, Thermal Protection, High Temperature Class H Insulation...





Physical Specifications:

• Frame Size: 63 x 63mm

• Body Length: 160mm

• Shaft Diameter: 5mm

• Number of Leads: 2

• Leads Length: 300mm

• Weight: 3.05g
