Permanent Magnet Peniculus dc Motor 63ZYT Series JK63ZYT02A-24V 3100Rpm 0.31mN.m 100W L=110mm Motor

Jkongmotor 24V 63ZYT Series scoparum dc motoriis (JK63ZYT02A 24V) cum 3100Rpm celeritate et magnitudine 63x63x110 mm. Fila 2 habet, 0.31mN.m et 100W. Pro magis differentibus dc penicillo motorum (qualia sunt gearbox, fregit, encoder, aut alias partes), pete nobis !!!

Electrical Specifications

• Type: 24V 3100Rpm Brushed Dc Motor

• Exemplar Nomen: JK63ZYT02A-24V

• Rated intentione: 24V (Option for 12v up to 60vdc)

• Ratum Speed: 3100Rpm

• Non Load Speed: 3600Rpm


• Rated Torque: 0.31mN.m

• Ratum Power: 100W

• Praesidium Level: IP50

• Partes libitum: Customized Voltage, Winding, Shaft, Ascensing, and Plumbe Configurations, EMI/RFI Suppressio Ambitus, Praesidium Thermal, High Temperature Class H Insulation...





Specificationes physicae:

• Frame Size: 63 x 63mm

• Corpus Longitudo: 110mm

• Shaft Diameter: 5mm

• Numerus Leads: 2

• Ducit Longitudo: 300mm

• Pondus: 1.20g
