Permanent Magnet Brush Dc Motor 90ZYT Series JK90ZYT-S01A 3000Rpm 1.5N.m 471W L=155mm Brushed Motor

Jkongmotor 24V 90ZYT Series  brushed dc motor (JK90ZYT-S01A) with 3000Rpm speed and size 90x90x155mm. It has 2 wires, 1.5N.m and 471W. For more different dc brush motors requirements (such as gearbox, brake, encoder, or other parts), please contact us!!!

Electrical Specifications：

• Type: 24V 3000Rpm Brushed Dc Motor

• Model Name: JK90ZYT-S01A

• Rated Voltage: 24V (Option for 12v up to 220vdc)

• Rated Speed: 3000Rpm

• No Load Speed: 3600Rpm


• Rated Torque: 1.5N.m

• Rated Power: 471W

• Protection Level: IP54

• Optional Parts: Customized Voltage, Winding, Shaft, Mounting, and Lead Configurations, EMI/RFI Suppression Circuit, Thermal Protection, High Temperature Class H Insulation...





Physical Specifications:

• Frame Size: 90 x 90mm

• Body Length: 155mm

• Shaft Diameter: 5mm

• Number of Leads: 2

• Leads Length: 300mm

• Weight: 3.5kg
