Permanent Magnet Brush Dc Motor 90ZYT Series JK90ZYT-S03B 1800Rpm 3.0N.m 565W L=199mm Brushed Motor

Jkongmotor 24V 90ZYT Series  brushed dc motor (JK90ZYT-S03B) with 1800Rpm speed and size 90x90x199mm. It has 2 wires, 3.0N.m and 565W. For more different dc brush motors requirements (such as gearbox, brake, encoder, or other parts), please contact us!!!

Electrical Specifications：

• Type: 24V 1800Rpm Brushed Dc Motor

• Model Name: JK90ZYT-S03B

• Rated Voltage: 24V (Option for 12v up to 220vdc)

• Rated Speed: 1800Rpm

• No Load Speed: 2300Rpm


• Rated Torque: 3.0N.m

• Rated Power: 565W

• Protection Level: IP54

• Optional Parts: Customized Voltage, Winding, Shaft, Mounting, and Lead Configurations, EMI/RFI Suppression Circuit, Thermal Protection, High Temperature Class H Insulation...





Physical Specifications:

• Frame Size: 90 x 90mm

• Body Length: 199mm

• Shaft Diameter: 5mm

• Number of Leads: 2

• Leads Length: 300mm

• Weight: 4.5kg
