Permanent Magnet Brush Dc Motor 63ZYT Series JK63ZYT03B-24V 4000Rpm 0.40mN.m 168W L=125mm Brushed Motor

Jkongmotor 24V 63ZYT Series brushed dc motor (JK63ZYT03B 24V) with 4000Rpm speed and size 63x63x125 mm. It has 2 wires,0.40mN.m and 168W. For more different dc brush motors requirements (such as gearbox, brake, encoder, or other parts), please contact us!!!

Electrical Specifications：

• Type: 24V 4000Rpm Brushed Dc Motor

• Model Name: JK63ZYT03B-24V

• Rated Voltage: 24V (Option for 12v up to 60vdc)

• Rated Speed: 4000Rpm

• No Load Speed: 4700Rpm


• Rated Torque: 0.40mN.m

• Rated Power: 168W

• Protection Level: IP50

• Optional Parts: Customized Voltage, Winding, Shaft, Mounting, and Lead Configurations, EMI/RFI Suppression Circuit, Thermal Protection, High Temperature Class H Insulation...





Physical Specifications:

• Frame Size: 63 x 63mm

• Body Length: 125mm

• Shaft Diameter: 5mm

• Number of Leads: 2

• Leads Length: 300mm

• Weight: 1.35g
