Permanent Magnet Brush Dc Motor 63ZYT Series JK63ZYT01B-24V 4000Rpm 0.2mN.m 84W L=95mm Brushed Motor

Jkongmotor 24V 63ZYT Series  brushed dc motor (JK63ZYT01B 24V) with 4000Rpm speed and size 63x63x95 mm. It has 2 wires,0.20mN.m and 84W. For more different dc brush motors requirements (such as gearbox, brake, encoder, or other parts), please contact us!!!

Electrical Specifications：

• Type: 24V 4000Rpm Brushed Dc Motor

• Model Name: JK63ZYT01B-24V

• Rated Voltage: 24V (Option for 12v up to 60vdc)

• Rated Speed: 4000Rpm

• No Load Speed: 4700Rpm


• Rated Torque: 0.20mN.m

• Rated Power: 84W

• Protection Level: IP50

• Optional Parts: Customized Voltage, Winding, Shaft, Mounting, and Lead Configurations, EMI/RFI Suppression Circuit, Thermal Protection, High Temperature Class H Insulation...





Physical Specifications:

• Frame Size: 63 x 63mm

• Body Length: 95mm

• Shaft Diameter: 5mm

• Number of Leads: 2

• Leads Length: 300mm

• Weight: 1.00g
