Permanent Magnet Brush Dc Motor 54ZYT Series JK54ZYT04A-24V 2810Rpm 0.353mN.m 76W L=145mm Brushed Motor

Jkongmotor 24V 54ZYT Series  brushed dc motor (JK54ZYT04A 24V) with 2810Rpm speed and size 54x54x145 mm. It has 2 wires,0.35mN.m and 104W. For more different dc brush motors requirements (such as gearbox, brake, encoder, or other parts), please contact us!!!

Electrical Specifications：

• Type: 24V 2810Rpm Brushed Dc Motor

• Model Name: JK54ZYT04A-24V

• Rated Voltage: 24V (Option for 12v up to 60vdc)

• Rated Speed: 2810Rpm

• No Load Speed: 3160Rpm


• Rated Torque:0.35mN.m

• Rated Power: 104W

• Protection Level: IP50

• Optional Parts: Customized Voltage, Winding, Shaft, Mounting, and Lead Configurations, EMI/RFI Suppression Circuit, Thermal Protection, High Temperature Class H Insulation...





Physical Specifications:

• Frame Size: 54 x 54mm

• Body Length: 145mm

• Shaft Diameter: 5mm

• Number of Leads: 2

• Leads Length: 300mm

• Weight: 1.55g
