Permanent Magnet Brush Dc Motor 52ZYT Series JK52ZYT01A-24V 3700Rpm 0.11N.m 42W L=95mm Brushed Motor

Jkongmotor 24V 52ZYT Series  brushed dc motor (JK52ZYT01A-24V) with 3700Rpm speed and size 52x52x95mm. It has 2 wires, 0.11N.m and 42W. For more different dc brush motors requirements (such as gearbox, brake, encoder, or other parts), please contact us!!!

Electrical Specifications：

• Type: 24V 3700Rpm Brushed Dc Motor

• Model Name: JK52ZYT01A

• Rated Voltage: 24V (Option for 12v up to 60vdc)

• Rated Speed: 3700Rpm

• No Load Speed: 4200Rpm


• Rated Torque: 0.11N.m

• Rated Power: 42W

• Protection Level: IP50 (Option for IP 54)

• Optional Parts: Customized Voltage, Winding, Shaft, Mounting, and Lead Configurations, EMI/RFI Suppression Circuit, Thermal Protection, High Temperature Class H Insulation...





Physical Specifications:

• Frame Size: 52 x 52mm

• Body Length: 95mm

• Shaft Diameter: 5mm

• Number of Leads: 2

• Leads Length: 300mm

• Weight: 0.85kg
