JK3DM2207
JKONGMOTOR
10 Pcs
| Size: | |
|---|---|
The JK3MD2207 is full digital 3 phase stepper driver based on DSP control. As a new generation of digital stepper motor drives, it is combined the advanced DSP control chip with the three-phase inverter driver module.The drive voltage of which is from 160V to 230VAC.It is designed for using with the 3 phase hybrid stepper motor of all kinds with 0.57mm to 130mm outside diameter, regulated phase current from 1.3A to 7.0A. The circuit that it adopts is similar to the circuit of servo control which enables the motor to run smoothly without noise and vibration. Moreover, its torque is far greater than 2 and 5 phase hybrid stepping motors.Furthemore, the highest micro step is 60000ppr. Due to these obvious advangtages, it is widely used in middle and big size numerical control devices such as curving machine, CNC machine, computer embroider machine, packing machine and etc.
● Current of winding will be reduced by approximately 50% when no step pulse command is received for 1.5 second
The JK3MD2207 is full digital 3 phase stepper driver based on DSP control. As a new generation of digital stepper motor drives, it is combined the advanced DSP control chip with the three-phase inverter driver module.The drive voltage of which is from 160V to 230VAC.It is designed for using with the 3 phase hybrid stepper motor of all kinds with 0.57mm to 130mm outside diameter, regulated phase current from 1.3A to 7.0A. The circuit that it adopts is similar to the circuit of servo control which enables the motor to run smoothly without noise and vibration. Moreover, its torque is far greater than 2 and 5 phase hybrid stepping motors.Furthemore, the highest micro step is 60000ppr. Due to these obvious advangtages, it is widely used in middle and big size numerical control devices such as curving machine, CNC machine, computer embroider machine, packing machine and etc.
● Current of winding will be reduced by approximately 50% when no step pulse command is received for 1.5 second
