Nema 23 JK57HS100-3004 Hybrid Stepper Motor 1.8 Degree 2.8N.m (396.51oz.in) 57x57x100mm 3.0A 4 Wires

Type: Nema23 2Phase Bipolar Stepper Motor

Current: 3A

Resistance: 0.75Ω

Rated Torque: 2.8N.m(396.51oz.in)

Model:
JK57HS100-3004
Brand:
JKONGMOTOR
Steper Motor Kinds:
Open Loop Motors
Stepper Motor Size:
Nema23 (57mm)
Number of Leads:
4wires
Phase:
2 phase
Step Angle:
1.8°
MOQ:
10 Pcs


Availability:



Inquire

Jkongmotor Nema 23 bipolar stepping motor (JK57HS100-3004) with step angle 1.8deg and size 57x57x100mm. It has 4 wires, 3A, 0.75Ω 3mH and with holding torque 2.8N.m(396.51oz.in). For more different stepper motors requirements (such as gearbox, brake, encoder, or integrated motors), please contact us!!!

Electrical Specifications：

Type: Nema23 bipolar stepper motor
Model Name: JK57HS100-3004
Phase: 2
Step Angle: 1.8 degree
Current: 3.0A
Resistance: 0.75Ω±0.1(20℃)
Inductance: 3mH±20%(1kHz 1V RMS)
Holding Torque: 2.8N.cm (396.51oz.in)
Insulation Class: B(130°); 80K Max.
Optional Parts: Gearbox, Encoder, Brake, Integrated Driver...

Physical Specifications:

Frame Size: Nema 23 ( 57 x 57mm)
Body Length: 100mm
Shaft Diameter: 8mm
Shaft Length: 21mm

Wires Connection:

A+	A-	B+	B-
Black	Green	Red	Blue
