External T-type linear Stepper Motors

Stepper motors enable accurate positioning with ease. They are used in various types of equipment for accurate rotation angle and speed control using pulse signals. Stepper motors generate high torque with a compact body, and are ideal for quick acceleration and response.

Jkongmotor offers many solutions for a wide variety of applications:

Closed Loop Stepper Motors, 2-Phase Stepper Motors, 3-Phase Stepper Motors, or 4-Phase Stepper Motor
Geared, Encoder and Electromagnetic Brake options
AC or DC Input Stepper Motor Drivers
Integrated Stepper Servo Motor
Frame Sizes from 0.79 in. (20 mm) up to 5.12in. (130 mm)

If you need more details on any specific type or application, let me know!

Features:

Direct Linear Motion Without Conversion Mechanisms
High-Precision Step Control
Compact and Low-Profile Design
Integrated Linear Guidance and Stability
High Thrust Output
Customizable Stroke Lengths
Robust Structural Design
Easy Mounting and Integration
Closed-Loop Control Compatibility
Energy-Efficient Operation

Jkongmotor External T-type linear Stepper Motors:

Introductions of External T-type linear Stepper Motors:

What Is External T-type Linear Stepper Motor?
What is enternal t-type linear stepper motor?An external T-type linear stepper motor is a specialized form of linear stepper actuator designed to convert the rotational movement of a stepper motor into controlled linear motion, using a T-shaped slider that moves externally along a threaded shaft. Th Read More
Stepper Motor Modes of Operation
Stepper motors can operate in several different modes, each offering unique advantages in terms of precision, torque, smoothness, and speed. The most common modes of operation are Full Step, Half Step, and Microstepping. Understanding these modes is crucial when selecting a motor for a specific application. Read More
Applications of 2-Phase Stepper Motors
2-phase stepper motors are a go-to solution for countless industries due to their high precision, reliable motion control, and simple digital interface. These motors excel in systems where accurate, repeatable positioning is essential, often without the need for complex feedback mechanisms. From high-speed printing to delicate medical equipment, 2-phase stepper motors power a wide range of critical technologies. Read More

Features of Stepper Motors:

Stepper motors are known for their precise positioning, repeatable movement, and high torque at low speeds. They are also reliable and require little maintenance due to their brushless design. Stepper motors are also relatively inexpensive compared to other types of motors.

Below are the key features of stepper motors:

1. Precise Position Control

Stepper motors move in discrete steps, allowing for high-precision control of angular position without requiring feedback systems like encoders.

2. Open-Loop Operation

Stepper motors operate in an open-loop system, which means they don’t require feedback to determine the rotor’s position.

3. Excellent Torque at Low Speeds

Stepper motors deliver high torque at low rotational speeds, making them perfect for applications where slow, controlled movements are needed.

4. Holding Torque

When the stepper motor is powered but not rotating, it can hold its position firmly, even against external forces.

5. Simple and Cost-Effective Drive Electronics

Stepper motors can be driven by basic electronic controllers using digital pulses.

6. Repeatability

Because they always move a fixed step for each input pulse, stepper motors are highly repeatable.

7. Compatibility with Microstepping

Most stepper motors support microstepping, which divides each step into smaller increments.

8. Bidirectional Movement

They can rotate clockwise or counterclockwise with equal ease.

9. Wide Range of Sizes and Types

Available in various frame sizes, stepper motors can be matched to small and large-scale applications alike.

10. Immediate Start, Stop, and Reverse

Stepper motors respond instantly to input signals without the need for acceleration or deceleration phases.

11. No Tuning Required

Unlike servo motors, stepper motors do not require PID tuning or sophisticated setup procedures.

FAQs About External Linear Stepper Motor and Customization

1. What is an external linear stepper motor?

An external linear stepper motor combines a stepper motor with an external threaded lead screw to convert rotary motion into controlled linear motion.

2. What is an external lead screw stepper motor?

An external lead screw stepper motor uses a lead screw mounted outside the motor to create precise linear travel for automation tasks.

3. What are the advantages of a stepper motor with lead screw?

Stepper motors with lead screws provide high precision, repeatability, compact design, and direct linear motion without extra conversion mechanisms.

4. Can Jkongmotor provide OEM ODM Customized external linear stepper motor solutions?

Yes, Jkongmotor supports OEM ODM Customized external linear stepper motors tailored to your mechanical, electrical, and performance requirements.

5. What customization options are available for external lead screw stepper motors?

Customization includes stroke length, screw type (T-type or ball screw), lead, screw length, connectors, and integrated accessories.

6. Can I customize stroke length on an external linear stepper motor?

Yes, stroke length and effective travel distance can be configured to match application needs.

7. Are different lead screw types supported?

Jkongmotor offers external T-type lead screws and external ball screws for different precision and load requirements.

8. Can the screw lead and pitch be customized?

Yes, screw lead, pitch, and size can be tailored through OEM ODM Customized services to optimize speed and travel.

9. What frame sizes are available for external linear stepper motors?

Available sizes cover NEMA 8, 11, 14, 17, 23, 24, and 34, fitting a range of application scales.

10. Can I customize connectors and wiring for a stepper motor with lead screw?

Yes, connectors, cable length, and termination types can be specified for assembly and integration ease.

11. Are integrated drivers or built-in electronics available?

Optional integrated drivers and electronics can be added as part of customization for simplified control.

12. Can Jkongmotor customize encoders and feedback options?

Yes, encoders and feedback devices can be integrated to provide position feedback and advanced control.

13. Is customization available for environmental protection?

External linear stepper motors can be adapted for dustproof, waterproof, and rugged environments when needed.

14. Can external linear stepper motors be configured for closed-loop control?

Yes, customization supports closed-loop control compatibility for systems that need feedback precision.

15. Are gearbox and brake accessories available as custom options?

Yes, gearbox, brake, and other mechanical accessories can be included per application requirements.

16. How does Jkongmotor ensure high thrust output with external lead screw stepper motors?

The combination of high-quality stepper motor and robust external screw design delivers strong thrust output and stable linear motion.

17. Can the motor performance be tailored to specific speeds and torque?

Yes, step angle, current rating, and torque profiles can be customized through OEM ODM services.

18. Are prototype and small batch options supported for custom motors?

Jkongmotor often supports prototyping and small batch production before larger OEM ODM Customized runs.

19. Can external linear stepper motors be made compact for space limited designs?

Yes, both compact body and low-profile designs are possible through tailored configurations.

20. How do I request a customized external linear stepper motor quote?

Provide details including load requirements, travel distance, screw type, environmental needs, and integration specifications for a tailored OEM ODM Customized quote.
