Nema 34 JK86HS115-6004 Hybrid Stepper Motor 1.8 Degree 8.7N.m (1232.02oz.in) 86x86x115mm 6.0A 4 Wires

Type: Nema34 Hybrid Bipolar Stepper Motor

Current: 6.0A

Resistance: 0.6Ω

Rated Torque: 8.7N.m(1232.02oz.in)

Model:
JK86HS115-6004
Brand:
JKONGMOTOR
Steper Motor Kinds:
Open Loop Motors
Stepper Motor Size:
Nema34 (86mm)
Number of Leads:
4wires
Phase:
2 phase
Step Angle:
1.8°
MOQ:
10 Pcs


Availability:



Inquire

Jkongmotor Nema 34 bipolar hybrid stepper motor (JK86HS115-6004) with step angle 1.8deg and size 86x86x115mm. It has 4 wires, 6.0A, 0.6Ω 6.5mH and with holding torque 8.7N.m(1232.02oz.in). For more different stepper motors requirements (such as gearbox, brake, encoder, or integrated motors), please contact us!!!

Electrical Specifications：

Type: Nema34 bipolar hybrid stepper motor
Model Name: JK86HS115-6004
Phase: 2
Step Angle: 1.8 degree
Current: 6.0A
Resistance: 0.6Ω±0.1(20℃)
Inductance: 6.5mH±20%(1kHz 1V RMS)
Holding Torque: 8.7N.cm (1232.02oz.in)
Insulation Class: B(130°); 80K Max.
Optional Parts: Gearbox, Encoder, Brake, Integrated Driver...

Physical Specifications:

Frame Size: Nema 34 ( 86 x 86mm)
Body Length: 115mm
Shaft Diameter: 12mm
Shaft Length: 32mm

Wires Connection:

A+	A-	B+	B-
Black	Green	Red	Blue
