Permanent Magnet Brush Dc Motor 42ZYT Series JK42ZYT04A-24V 3600Rpm 70mN.m 26W L=90mm Brushed Motor

Jkongmotor 24V 42ZYT Series  brushed dc motor (JK42ZYT04A-24V) with 3600Rpm speed and size 42x42x90mm. It has 2 wires, 70mN.m and 26W. For more different dc brush motors requirements (such as gearbox, brake, encoder, or other parts), please contact us!!!

Electrical Specifications：

• Type: 24V 3600Rpm Brushed Dc Motor

• Model Name: JK42ZYT04A

• Rated Voltage: 24V (Option for 12v up to 60vdc)

• Rated Speed: 3600Rpm

• No Load Speed: 4200Rpm


• Rated Torque: 70mN.m

• Rated Power: 26W

• Protection Level: IP40

• Optional Parts: Customized Voltage, Winding, Shaft, Mounting, and Lead Configurations, EMI/RFI Suppression Circuit, Thermal Protection, High Temperature Class H Insulation...





Physical Specifications:

• Frame Size: 42 x 42mm

• Body Length: 90mm

• Shaft Diameter: 5mm

• Number of Leads: 2

• Leads Length: 300mm

• Weight: 0.54kg
