Permanent Magnet Brush Dc Motor 42ZYT Series JK42ZYT03A-24V 3100Rpm 57mN.m 18W L=85mm Brushed Motor

Jkongmotor 24V 42ZYT Series  brushed dc motor (JK42ZYT03A-24V) with 3100Rpm speed and size 42x42x85mm. It has 2 wires, 57mN.m and 18W. For more different dc brush motors requirements (such as gearbox, brake, encoder, or other parts), please contact us!!!

Electrical Specifications：

• Type: 24V 3100Rpm Brushed Dc Motor

• Model Name: JK42ZYT03A

• Rated Voltage: 24V (Option for 12v up to 60vdc)

• Rated Speed: 3100Rpm

• No Load Speed: 3800Rpm


• Rated Torque: 57mN.m

• Rated Power: 18W

• Protection Level: IP40

• Optional Parts: Customized Voltage, Winding, Shaft, Mounting, and Lead Configurations, EMI/RFI Suppression Circuit, Thermal Protection, High Temperature Class H Insulation...





Physical Specifications:

• Frame Size: 42 x 42mm

• Body Length: 85mm

• Shaft Diameter: 5mm

• Number of Leads: 2

• Leads Length: 300mm

• Weight: 0.50kg
